Description
-
Features
- Xmax = 19mm one-way by 70% BL
- RMS Power = 1000-watts
- Vented magnetic gap
- Optimized high-velocity pole vent
- Innovative high-velocity vented frame spacer ring
- Black Aluminum 2.5” voice coil former for superior heat dissipation
- High Temperature copper voice coil wire
- Large aluminum faraday ring (Magnet ID)
- Spring Loaded Terminals
- Stitched-On “XL” Tinsel Leads to prevent fatigue and failure
- High strength cast aluminum frame
- Optimized for small ported, sealed, & band-pass enclosures
- These features combine to create the optimized coil ventilation system.
SA CLASSIC 12"
T/S SPECS SA CLASSIC 12" D2 SA CLASSIC 12" D4 RE (Ohms) 4.57 7.07 FS (Hz) 33.71 33.96 VAS (L) 21.21 24.63 Qes 0.58 0.55 Qms 5.34 5.15 Qts 0.52 0.49 Le (mH) 3.40 4.84 BL (NA) 21.64 25.67 Mms (Grams) 280 237 Cms (uM/N) 79.43 92.27 Sens (dB @ 1w/1m) 83.21 84.22
