Description
-
Features
- Xmax = 14mm one-way by 70% BL
- RMS Power = 750-watts (300-watts 8”)
- Vented magnetic gap
- Vented pole piece with optimized geometry (solid pole for 8”)
- Black Aluminum 2.5” voice coil former for superior heat dissipation (2” coil for 8”)
- High Temperature 4-Layer copper voice coil wire
- Spring Loaded Terminals
- Stitched-On “Mini-XL” Tinsel Leads to prevent fatigue and failure
- Bolted-on Spider Pack
- Bolt-through motor design to ensure maximum longevity and ruggedness against mechanical failures
- High strength stamped steel frame
- Optimized for ported enclosures
T/S SPECS E V.4 12" D2 E V.4 12" D4 RE (Ohms) 4.030 6.130 FS (Hz) 28.480 28.373 VAS (L) 53.059 54.292 Qes 0.509 0.570 Qms 5.249 3.542 Qts 0.464 0.491 BL (NA) 17.576 20.249 Mms (Grams) 217.987 213.033 Cms (mm/N) 143.258 146.589 Sens (dB @ 1w/1m) 85.7 85.3
