Description
-
Features
- Xmax = 14mm one-way by 70% BL
- RMS Power = 750-watts (300-watts 8”)
- Vented magnetic gap
- Vented pole piece with optimized geometry (solid pole for 8”)
- Black Aluminum 2.5” voice coil former for superior heat dissipation (2” coil for 8”)
- High Temperature 4-Layer copper voice coil wire
- Spring Loaded Terminals
- Stitched-On “Mini-XL” Tinsel Leads to prevent fatigue and failure
- Bolted-on Spider Pack
- Bolt-through motor design to ensure maximum longevity and ruggedness against mechanical failures
- High strength stamped steel frame
- Optimized for ported enclosures
T/S SPECS E V.4 10" D2 E V.4 10" D4 RE (Ohms) 4.030 6.130 FS (Hz) 33.270 33.227 VAS (L) 21.124 21.074 Qes 0.525 0.556 Qms 3.657 3.424 Qts 0.459 0.478 BL (NA) 16.392 19.696 Mms (Grams) 167.587 168.412 Cms (mm/N) 136.554 136.231 Sens (dB @ 1w/1m) 83.6 83.3
