Description
FEATURES
- Digital Class-D Mono Block Amplifier
- Dual MOS-FET PWM Power Supply
- 1 Ohm Stable Load
- 12 dB/Octave – Variable Low Pass Filter
- 12 dB/Octave – Variable High Pass Filter
- 9 dB/Octave – Variable Bass Boost
- 4 Way Protection Ciruit (Thermal, Voltage, Speaker Short, DC Offset)
- Wired Remote Control with Clipping Indicator
SPECIFICATIONS
- 1 ohm Mono RMS 600W
- 2 ohm Mono RMS 350W
- 4 ohm Mono RMS 250W
- Recommended Fuse Rating 60A
- Low Pass Filter (Variable) 80Hz-20kHz
- High Pass Filter (Variable) 15Hz-1kHz
- Bass Boost @ 50Hz 0-12dB
- Input Sensitivity 5V Max
- S/N Ratio 86dB
- Working Voltage 10.5v-15.5v
- Dimensions 7.25" x 5.00" x 2.50"
