Description
- 1 Ch Full-Range Class D Amplifier
- RMS Output Power @ 14.4V (4 OHM) 3,000W RMS
- RMS Output Power @ 14.4V (2 OHM) 3,250W RMS
- RMS Output Power @ 14.4V (1 OHM) 3,500W RMS
- INPUT SENSITIVITY: 200MV
- Signal-to-Noise Ratio: 100dB Frequency Response: 10Hz-20KHz (-3dB)
- Crossover: H.P.F. (High Pass Filter) 10 to 1 KHz(-12dB/8) Variable
- L.P.F. (Low Pass Filter) 40 to 20 KHz(-12dB/8) Variable
- Bass Boost: 0-12dB (50Hz)
- Input Impedance: 56k Ohms
- Protection System: Output Short/High/Low Supply
- Voltage/Thermal Protection
- Minimum Supply Voltage: 9V
- Maximum Supply Voltage: 16V
