Description
Features
- 1 x 350 watts @ 4 Ohms
- 1 x 600 Watts @ 2 Ohms
- IPX6 Rated
- GTOTM Signal Sense
- Optional wired ACR-1 Remote Control for Output Level
- High and low input modes
- Linkwitz-Riley Crossover
Inputs
- Preamp/Speaker Level Inputs: 2
- Input Voltage Low: 500 mV – 6 Vrms
- Input Voltage Range High: 1 Vrms – 12 Vrms
Outputs
- Rated Continuous (RMS) Power at 14.4V:
- 4 Ω – 350 W x 1
- 2 Ω – 600 W x 1
Performance
- Frequency Response: 26 Hz – 22 kHz
- Signal to Noise: 102 dBA, Ref 50 W @ 4 Ohm
- THD+N: < 0.05%
- Crossover: 12 dB/octave Linkwitz-Riley, 80 Hz, 120 Hz, Bypass
- IP Rating: IPX6
General
- Recommended Fuse Rating: 30A
Weights & Dimensions
- Dimensions: 8.89″W x 5.31″D x 2.36″H
- Weight: 4.45 lbs. (2.02 kg)
in the box: ACX-600.1, Manual, Warranty
